DBW-L2326-2SA - Bohle BT Kit Wall Mount with Sidelite - 236in - 264lbs - Double Doors - Satin Anodized
Product Description
Product Info
This kit provides everything needed to install a two, wall mounted, soft close sliding door with fixed profiles for a sidelite.
About MasterTrack® BT
The MasterTrack® BT custom sliding door series is engineered for versatile installation environments — surpassing standard ceiling or wall-mounted setups. Designed with flexibility in mind, the modular MasterTrack® BT system enables limitless interior design possibilities. Whether you're configuring multi-panel runners, pocket doors or seamless flush-to-ceiling sliding doors, this system supports rapid installation using just a few key components, including a compact track with an integrated glass suspension for a modern, minimalist appearance.
Product Highlights
- Ultra-Smooth Rolling Performance
- Effortless Glide with Every Use
- Quiet, Controlled Soft-Open & Soft-Close Action
- Box Track Has Zero Risk of Derailment
- Modular Design Scales with Any Weight Requirement
- Durable, All-Metal Dampers with Premium Hydraulic Control
Technical Info
- Material: Aluminum
- Mounting Style: Wall
- Max Weight lbs: 264 lbs
- For Glass Thickness: 3/8-1/2"
- Finish: Satin Anodized
- Length: 236 Inches
- Weight lbs: 46.4
- No glass processing required
- Pre drilled track every 7 7/8"
What's Included
- 1x Standard Running Track - 236" Length - Satin Anodized - BO5806011
- 4x Carriage with Soft Close - 264 lbs - BO5800120
- 4x Standard Glass Clamp - BO5800001
- 2x Bottom Guide - Satin Anodized - BO5700005
- 1x Standard Cover - 236" Length - Satin Anodized - BO5806021
- 3x Fixed Panel Profile - 78" Length - Satin Anodized - BO5802031
- 2x U-Channel 1 x 1 x 120" - Satin Anodized - BA6703448
